Technical data
True scale
Sourced dimensions beside a 1.75 m human reference.
Points represent sourced observations, including revisions. Revisions on the same effective date are not separate inventory events. Ranges appear in the table and are not plotted as exact points.
| Observation / report period | Value | Source | Claim state |
|---|---|---|---|
| 28 Sept 2026 | 11.6 m | Wikipedia contributors | approved |
| 28 Sept 2026 | 11.6 m | Wikipedia contributors | superseded |
Howitzer
Sweden
1978 – present
Operators
Kargil War
Bofors
1978
Bofors
$695,000 (1986)
1978–1984
720
See Variants
11,500 kg (25,400 lb )
Combat: 11.60 m (38 ft 1 in)
5.89 m (19 ft 4 in) L/38
Combat: 9.73 m (31 ft 11 in)
9 to 14
155 mm NATO
155 mm
semi-fixed ammunition, propellant charge is contained in a plastic cartridge case with a steel head
Vertically sliding breech block, hydraulic ramming
split trail with castor wheels
-5°/+70°
30° left or right from centreline
4 rounds in 9 seconds, 6 rounds in 25 seconds, sustained 3 revolutions per minute for 20 minutes
300 to 770 m/s (980 to 2,530 ft/s)
21 km (13 mi)
24 km (15 mi) (with base bleed -round) 60 km+ (using ramjet-round )
hydraulically powered flick rammer assisted loading
Volvo B20 APU
6 km/h
Reference text from Wikipedia contributors, used under CC BY-SA 4.0.
Haubits FH77 equipment records. Variants, orders and quantities are shown as reported in each inventory source; coverage is incomplete.
India
NigeriaReported count for Haubits FH77. Service scope: Nigerian Army; does not replace a national total. 1 distinct count cell(s) from the same source list; shared rowspan cells counted once. Excludes retired/reserve/on-order rows. Count column(s): quantity: 24. Origin: Sweden. The listed variants/roles are the scope, not an immediately deployable count. The components do not establish one inventory census date; the stored date is the retrieved source snapshot.
Sweden
