At a glance
Iveco MTVlarger figure on 0 of 1
JCB HMEE
Measured figures
Length
Single source5,900 mm (230 in)[source]
Length
Single sourceConfiguration
| Specification | Iveco MTV | JCB HMEE |
|---|---|---|
| Crew | Iveco variant: 1 driver + up to 7 pax Hardtop: 2 crew + 2 pax Softtop: 2 crew + 2 pax Utility: 2 Ambulance: 2 crew + 2 injured Military police: 2 + 6[source] | 1 or 2[source] |
| Type | Infantry mobility vehicle[source] | Backhoe loader[source] |
| Place of origin | Italy[source] | United Kingdom United States[source] |
| In service | 2024–present[source] | — |
Counts only measures both sources give with the same scope. A larger figure is not a better system.
6x6
Single source9.45 to 10.10 m (372 to 398 in) 6x6: 6.9 m (270 in)[source]
FPT NEF N67 280 (6.7 litres, inline-six , turbo-diesel engine , Euro III) Power Torque: 1,000 N⋅m (740 ft⋅lb)
Single sourceFPT NEF N67 280 (6.7 litres, inline-six , turbo-diesel engine , Euro III) Power: 276 hp (206 kW) Torque: 1,000 N⋅m (740 ft⋅lb))[source]
Cummins 6.7 QSB 705 N⋅m (520 lb⋅ft)
Single sourceCummins 6.7 QSB 149 kW (203 PS) 705 N⋅m (520 lb⋅ft)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Used by |
|---|
Netherlands Armed Forces[source] |
Australia , Belgium , Denmark , Germany , Ireland , Israel , New Zealand , Spain , Sweden , Ukraine , United Kingdom , United States[source] |
| Designer | Iveco Defence Vehicles[source] | — |
|---|
| No. built | 200 (as of October 2024, with a total of 1,185 on order)[source] | >900 (as of 2020)[source] |
|---|
| Variants | See variants[source] | — |
|---|
| Main armament | Hardtop: FN deFNder RCWS equipped with an FN MAG ( 7.62×51mm NATO ) Softtop variant, manned ring mount with optionally: M2 Browning ( 12.7×99mm NATO HMG ) H&K GMG ( 40×53 mm HV , AGL ) Spike LR / LR2 ( ATGM )[source] | — |
|---|
| Secondary armament | Softtop variant: lateral swing mount for the softtop variant, with a FN MAG ( 7.62×51mm NATO , GPMG )[source] | — |
|---|
| Power/weight | 23 hp/t (17 kW/t)[source] | — |
|---|
| Payload capacity | Payload: > 2.0 t (4,400 lb) Towing capacity: 3.5 t (7,700 lb)[source] | — |
|---|
| Transmission | Automatic High-low transfer case Permanent 4×4 wheel-drive 3 fully lockable differentials[source] | ZF Ergopower transmission (6 gears forward, 2 backwards)[source] |
|---|
| Ground clearance | 350 mm (14 in) (vertical obstacle)[source] | 0.4 m (16 in)[source] |
|---|
| Manufacturer | Iveco Defence Vehicles[source] | JCB[source] |
|---|
| Wars | — | War in Afghanistan Russian invasion of Ukraine[source] |
|---|
| Produced | — | 2007–present[source] |
|---|
| Armor | — | A-kit: standard unprotected B-kit: applique and transparent armour C-kit (Theatre Entry Standard): blast mitigation belly plate, internal spall liner, slat armour, capacity for electronic counter-measures and situational awareness.[source] |
|---|
