Measured figures
Approximate width in Trackfire product technical specification
Single source~1050 mm[source]Approximate width in Trackfire product technical specification
Configuration
| Specification | Aselsan SMASH 200/25 | Saab Trackfire |
|---|---|---|
| Type | Remote controlled weapon station[source] | remote weapon station[source] |
| Place of origin | Turkey[source] | — |
| Designer | Aselsan[source] | — |
| Manufacturer | Aselsan[source] | Saab Group[source] |
| Shell | 25×137mm |
Approximate height in Trackfire product technical specification
Single source~950 mm[source]Approximate height in Trackfire product technical specification
Including gun and 250 round ammunition
Single source1,350 kilograms (2,980 lb) (Including gun and 250 round ammunition)[source]
Approximate director-unit mass; excludes weapons and ammunition
Single source~280 kg (excl. weapons and ammunition)[source]Approximate director-unit mass; excludes weapons and ammunition
Effective; M242 Bushmaster
Single sourceEffective; Oerlikon KBA
Single sourceOerlikon KBA: 3,020 metres (9,910 ft) M242 Bushmaster: 3,000 metres (9,800 ft)[source]
M242 Bushmaster
Single sourceOerlikon KBA
Single sourceOerlikon KBA: 1,400 metres per second (4,600 ft/s) M242 Bushmaster: 1,100 metres per second (3,600 ft/s)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| — |
| Action | Gas-operated (Oerlikon KBA)[source] | — |
|---|
| Elevation | -15 (±2)° to +55 (±2)° (gun) -30 (±2)° / +80 (±2)° (EO sights)[source] | -20° till +55°[source]Armament vertical angular limits |
|---|
| Traverse | 135° (without slipring) 360° (with slipring) Angular speed: 60 degrees per second (both for the gun and EO sights)[source] | nx360° (full 360-degree continuous rotation)[source]Continuous weapon/director-unit azimuth rotation |
|---|
| Rate of fire | 450-600 rounds/minutes[source] | — |
|---|
| Feed system | Dual[source] | — |
|---|
| Sights | Thermal camera, TV camera and laser range finder[source] | — |
|---|
| Role | — | remotely operated weapon system[source] |
|---|
| Armament | — | medium or light caliber weapons[source] M2 12.7 mm heavy machine gun, 30x113 mm M230LF Bushmaster chain gun.[source]Configurable primary weapon examples; no gun inferred as standard on every installation |
|---|
| Mounting | — | vehicles, ships and stationary platforms[source] |
|---|
| Used by | — | Finnish Navy[source] |
|---|
| Sensor spectral band | — | 3 – 5 µm[source]Thermal sensor spectral band |
|---|
| Day camera field of view | — | 40°- 2° optical zoom[source]Day-camera optical zoom angular field |
|---|
| Laser rangefinder | — | >4000 meter, <+/- 5 m[source]Range lower bound and accuracy upper bound as reported; not an exact maximum range |
|---|
| Sensor elevation | — | -20° to +55[source]Sensor vertical angular limits |
|---|
| Sensor azimuth | — | +/-15° relative DU azimuth axis[source]Sensor side angle relative to Director Unit |
|---|
| Secondary armament | — | FN MAG 58 7.62 mm general purpose machine gun[source]Configurable secondary weapon example |
|---|
| Angular velocity | — | 120 deg/s (max)[source]Maximum azimuth and elevation angular velocity |
|---|
| Angular acceleration | — | 400 deg/s²[source]Azimuth and elevation angular acceleration |
|---|
| Operating temperature | — | -30°C to +55°C[source]Specified operational temperature limits |
|---|
| Environmental standards | — | MIL-STD-461F and MIL-STD-810G[source]Manufacturer-reported qualification standards |
|---|
| Main units | — | Director Unit (DU) Sensor Module (SM) Human Machine Interface (HMI) Gunners Display (GD) Fire Control Panel (FCP) Control Handle (CH) Video Tracker (VT)[source]Trackfire system components |
|---|
| Sights and sensors | — | Cooled IRV-sensor in spectral band 3 – 5 µm IRV-sensor is equipped with electrical image processing (NIR- and polarization filter) Day camera with 40°- 2° optical zoom Laser Range Finder (LRF) (Class 1, Eyesafe): >4000 meter, <+/- 5 m[source]Source-named sensor suite; LRF limits remain open bounds, not exact range |
|---|
| Stabilisation | — | fully stabilised, remotely operated weapons and sensor system[source]Manufacturer describes stabilisation of remotely operated weapon and sensor system |
|---|
| National origin | — | Sweden[source]Explicit equipment-origin column for exact SaabTrackfire row; not the Finnish operator country or inferred manufacturer nationality |
|---|
| Reported operators |
| — |
|---|
