BPatrol & mine warfare vessels
At a glance
Pashe-class speedboatlarger figure on 1 of 4
Pulau Fani-class minehunterlarger figure on 3 of 4
Measured figures
Length
Single source19.5 m (64 ft 0 in)[source]
Length
Single sourceConfiguration
| Specification | Pashe-class speedboat | Pulau Fani-class minehunter |
|---|---|---|
| Power | Diesel[source] 2 × MWM TBD 234 V12 engines, 1,646 horsepower (1.227 MW) 2 × shafts[source] | 2 x MAN 12V175D-MM diesel engines, 2,220 kW (2,980 shp) 2 x controllable-pitch screws[source] |
| Builders | Marine Industries Organization[source] | Abeking & Rasmussen , Lemwerder[source] |
| Operators | Navy of the Islamic Revolutionary Guard Corps[source] | Indonesian Navy[source] |
Counts only measures both sources give with the same scope. A larger figure is not a better system.
61.4 m (201 ft 5 in)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Type | Fast patrol boat[source] | — |
|---|
| Sensors & processing systems | Surface search radar , I-band[source] | SYNTACS C2 mine countermeasure suite Synapsis NX navigation system[source] |
|---|
| Armament | 2 × 23mm/80 (twin)[source] | 1 x Oerlikon Searanger 20 RWS 2 x 9m SWATH mine hunting ROVs[source] |
|---|
| Alternative designation | Pashe[source] | — |
|---|
| Name | — | Pulau Fani class[source] |
|---|
| Preceded by | — | Pulau Rote class[source] |
|---|
| Subclasses | — | Frankenthal class[source] |
|---|
| Built | — | 2019–2023[source] |
|---|
| In commission | — | 2023–present[source] |
|---|
| Planned | — |
|---|
| Active | — |
|---|
| Class & type | — | Mine countermeasures vessel[source] |
|---|
| Boats & landing craft carried | — | 2 x 4 m RHIB[source] |
|---|
| Country of origin | — | Germany[source]Pulau Fani-class minehunter · literal inventory Origin field assigned to the exact equipment row linked in the primary inventory identity column; no operator, manufacturer location or parent/sibling specification inference |
|---|
