At a glance
Daguan-class troopshiplarger figure on 2 of 2
Knud Rasmussen-class patrol vessellarger figure on 0 of 2
Counts only measures both sources give with the same scope. A larger figure is not a better system.
Measured figures
Length
Single source196 metres (643 ft)[source]
Length
Single sourceConfiguration
| Specification | Daguan-class troopship | Knud Rasmussen-class patrol vessel |
|---|---|---|
| Power | — | 2 x MAN B&W Diesel ALPHA 8L27/38 generating 2,720 kW (3,650 hp) each through RENK reduction gear "Twin in/single out"[source] |
| Operators | People's Liberation Army Navy[source] | Royal Danish Navy[source] |
| In service | 2011 - present[source] | — |
| Completed | ||
| Active | 2 |
LOA LWL
Single sourceLOA 71.8 m (235 ft 7 in) LWL 61.0 m (200 ft 2 in)[source]
+ aircrew and transients (Accommodation for up to 43 in total)
Single source18 + aircrew and transients (Accommodation for up to 43 in total)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Type | Troopship / Training ship / "Comprehensive support ship"[source] | Ocean patrol craft[source] |
|---|
| Capacity | 2,500 support personnel[source] | — |
|---|
| Aviation facilities | Medium helicopter deck[source] | Aft helicopter deck[source] |
|---|
| Manufacturer | CSSC Offshore & Marine Engineering Company[source] | — |
|---|
| Aircraft carried | Each ship has a medium helicopter deck on its stern, which can accommodate one Changhe Z-8 heavy transport helicopter.[source]Stern helicopter-deck accommodation; not an embarked air-group assertion | — |
|---|
| Name | — | Knud Rasmussen class[source] |
|---|
| Builders | — | Karstensens Skibsværft Hull is built at the Polish Stocznia Pólnocna (Northern Shipyard) in Gdansk[source] |
|---|
| Preceded by | — | Agdlek class[source] |
|---|
| In commission | — | 2008–present[source] |
|---|
| Planned | — |
|---|
| Ice class | — | Finnish-Swedish ice class 1A Super/ Polar Class 6 )[source] |
|---|
| Boats & landing craft carried | — | 1 x SB90E for search and rescue , 1x 7 m (23 ft) RHIB , 1 x 4.8 metres (16 ft) RHIB[source] |
|---|
| Sensors & processing systems | — | 1 × Terma Scanter 4100 surface and air search radar 3 × Furuno navigation radars SAAB CEROS 200 radar and optronic tracking system and CWI illumination radar[source] |
|---|
| Armament | — | 2 StanFlex modules, with the following options each: 1 × 76 mm gun Mk M/85 LvSa gun, only in bow slot 1 × Mk.48 or Mk.56 VLS fitting 6 or 12 RIM-162 ESSM surface-to-air missiles respectively 8 × Harpoon Block II SSM in inclined launchers MU90 Impact ASW-torpedo launcher Others: 2 × 12.7 mm heavy machine gun M/01 LvSa[source] |
|---|
