At a glance
Measured figures
Chinook HC6A · Length
Single sourceChinook / RAF specification (variant not stated) · Length · Length
Single sourceConfiguration
| Specification | Boeing Chinook (UK variants) | Mil Mi-14 |
|---|---|---|
| Type | Transport helicopter[source] | Anti-submarine helicopter[source] |
| Manufacturer | Boeing Defense, Space & Security[source] | Mil Moscow Helicopter Plant[source] |
| Designer | Boeing-Vertol[source] | — |
| Status | In service[source] | In service[source] |
Mi-14PL · Length
Single source18.38 m (60 ft 4 in)[source]
Chinook HC6A · 2 ×
Single sourceChinook / RAF specification (variant not stated) · Rotor diameter · Rotor
Single source2 × 60 ft 0 in (18.29 m)[source]
18.29m[source]Chinook / RAF specification (variant not stated) · Rotor
Mi-14PL · Main rotor diameter
Single source21.29 m (69 ft 10 in)[source]
Empty; Chinook HC6A · Empty weight
Single sourceGross; Chinook HC6A · Gross weight
Single sourceMaximum take-off; Chinook HC6A · Max takeoff weight
Single source22,450 lb (10,183 kg)[source]
26,680 lb (12,102 kg)[source]
50,000 lb (22,680 kg)[source]
Empty; Mi-14PL · Empty weight
Single sourceMaximum take-off; Mi-14PL · Max takeoff weight
Single sourceChinook HC6A · pilot, copilot, two weapon system operators/loadmasters
Single source4 (pilot, copilot, two weapon system operators/loadmasters)[source]
2 Pilots, 2 Weapon System Operators[source]Chinook / RAF specification (variant not stated) · AircrewSource text · numeric interpretation needs review
Mi-14PL · Crew
Single sourceMaximum; Chinook HC6A · Maximum speed
Single sourceMaximum; Chinook / RAF specification (variant not stated) · Maximum speed · Maximum speed
Single source160 kn (180 mph, 300 km/h)[source]
160kt[source]Chinook / RAF specification (variant not stated) · Maximum speed
Maximum; Mi-14PL · Maximum speed
Single source230 km/h (140 mph, 120 kn)[source]
Chinook HC6A · 2 × Honeywell T55-GA-714A turboshaft free-turbine engines, 3,750 shp ( ) each
Single source2 × Honeywell T55-GA-714A turboshaft free-turbine engines, 3,750 shp (2,800 kW) each[source]
Mi-14PL · 2 × Klimov TV3-117MT turboshaft engines each
Single source2 × Klimov TV3-117MT turboshaft engines, 1,454 kW (1,950 hp) each[source]
Chinook HC6A · 1,980 ft/min ( )Thrust 2x 4,168shp each engine
Single source1,980 ft/min (10.1 m/s)Thrust 2x 4,168shp each engine[source]
Mi-14PL · with maximum fuel
Single source4 hours with maximum fuel[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Primary user |
|---|
Royal Air Force[source] |
| — |
| Number built | 72 (all RAF models)[source] | 273[source] |
|---|
| Introduction date | 22 November 1980 (with RAF)[source] | 1976[source] |
|---|
| First flight | 23 March 1980 (HC1)[source] | 1 August 1967[source] |
|---|
| Developed from | Boeing CH-47 Chinook[source] | Mil Mi-8[source] |
|---|
| Variants | HC1, HC1B, HC2, HC3, HC4, HC5, HC6, HC6A, HC7[source] | — |
|---|
| Capacity | 55 soldiers and up to 10 tonnes of freight or equipment[source] | — |
|---|
| Guns | 2× M134 Miniguns and 1× M60 machine gun[source] 2 x M134 Miniguns, 1 x M60 Machine Gun[source]Chinook / RAF specification (variant not stated) · Guns | — |
|---|
| Main rotor area | 5,655.2 sq ft (525.39 m 2 )[source] | 356 m 2 (3,830 sq ft)[source] |
|---|
| Blade section | - root: Boeing VR-7; tip: Boeing VR-8[source] | NACA 23012[source] |
|---|
| Cockpit Avionics | Glass cockpit with a BAE Systems Digital Advanced Flight Control System (DAFCS), includes automatic modes such as auto-hover and auto-descend to ease pilot workload.[source] | — |
|---|
| Sensors | Electro-Optical Sensor Turret (EOST) with two infrared cameras and a low-light TV function .[source] EOST turret including two infrared cameras and a low-light TV function[source]Chinook / RAF specification (variant not stated) · Electro optics | — |
|---|
| Defensive Aids | Missile Warning Receiver, Infrared Warning Receiver, Radar Warning Receiver, Counter-measure dispensing system (flares).[source] | — |
|---|
| Country of origin | United States[source]Boeing Chinook (UK variants) · origin explicitly stated in the linked current national-inventory row; no inference from operator or shipyard | — |
|---|
| Powerplant | Two Honeywell 55-L-714A Free-Turbine engines[source]Chinook / RAF specification (variant not stated) · Powerplant | — |
|---|
| Reported engine rating | 4,168shp each[source]Chinook / RAF specification (variant not stated) · ThrustSource text · numeric interpretation needs review | — |
|---|
| Flight altitude | 15,000ft[source]Chinook / RAF specification (variant not stated) · Maximum altitude | — |
|---|
| National origin | — | Soviet Union[source] |
|---|
| Primary users | — | Soviet Navy Russian Navy Ukrainian Navy Polish Navy[source] |
|---|
| Manufactured | — | 1969-1986[source] |
|---|
