At a glance
Measured figures
Bell 412EP · including rotors
Single source56 ft 1 in (17.09 m) including rotors[source]
excluding rotors
Single sourceConfiguration
| Specification | Bell 412 | Mil Mi-28 |
|---|---|---|
| Type | Multipurpose utility helicopter[source] | Attack helicopter[source] |
| National origin | United States / Canada[source] | Soviet Union Russia[source] |
| Manufacturer | Bell Helicopter[source] | Mil[source] |
| Primary users | Japan Ground Self Defence Force See Operators for others[source] | Russian Air Force Algerian Air Force Iraqi Army Aviation Command Uganda Air Force |
17.01 m (55 ft 10 in) excluding rotors[source]
stub wings
Single source4.88 m (16 ft 0 in) stub wings[source]
10-minute loiter with 5% reserve
Single source200 km (120 mi, 110 nmi) 10-minute loiter with 5% reserve[source]
Bell 412EP · 1 × Pratt & Whitney Canada PT6T-3D Twin-Pac or PT6T-3DF Twin-Pac coupled turboshaft engine - each, 1,250 shp (
Single source1 × Pratt & Whitney Canada PT6T-3D Twin-Pac or PT6T-3DF Twin-Pac coupled turboshaft engine - each, 1,250 shp (930 kW)[source]
2 × Klimov VK-2500 turboshaft engines each
Single source2 × Klimov VK-2500 turboshaft engines, 1,636 kW (2,194 hp) each[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Number built | 1,300+[source] | 190+ as of May 2025[source] |
|---|
| Manufactured | 1979–present[source] | 1982–present[source] |
|---|
| Introduction date | 1981 ( 1981 )[source] | 15 October 2009 (Mi-28N)[source] |
|---|
| First flight | August 1979 ( 1979-08 )[source] | 10 November 1982[source] |
|---|
| Developed from | Bell 212[source] | — |
|---|
| Variant | Bell CH-146 Griffon[source] | — |
|---|
| Capacity | up to 13 passengers, maximum external load of almost 6,614 lb (3,000 kg)[source] | — |
|---|
| Fuselage length | 43 ft (13 m)[source] | — |
|---|
| Blade sections | root: Boeing VR-7; tip: Wortmann FX 71-H-080[source] | — |
|---|
| Main rotor area | 1,662 sq ft (154.4 m 2 )[source] | 232.35 m 2 (2,501.0 sq ft)[source] |
|---|
| Power/mass | 0.2663 hp/lb (0.4378 kW/kg)[source] | 0.31 kW/kg (0.19 hp/lb)[source] |
|---|
| Designer | — | Marat Tishchenko[source] |
|---|
| Status | — | In service[source] |
|---|
| Fuel capacity | — | 1,337 kg (2,948 lb) / 1,720 L (450 US gal; 380 imp gal) internal fuel + up to 445 kg (981 lb) / 571 L (151 US gal; 126 imp gal) in 4x drop tanks[source] |
|---|
| Guns | — | 1× chin-mounted 30 mm Shipunov 2A42 cannon with 250 rounds (±110° horizontal fire)[source] |
|---|
| Hardpoints | — | Two pylons under each stub wing to mount bombs, rockets, missiles, and gun pods. Main armament configurations include: 16 Ataka-V anti-tank missiles and 40 S-8 rockets , or 16 Ataka-V anti-tank missiles, and 10 S-13 rocket , or 16 Ataka-V anti-tank missiles, and two 23 mm UPK-23-250 gun pods each containing a GSh-23L with 250 rounds. Other ordnance: 9K121 Vikhr , and 9M123 Khrizantema anti-tank missiles ( 9M123VM variant for any Mi-28 variant have fire-control radar , with bonus of millimeter-wave radar ACLOS missile guidance), LMUR , 8 Igla-V and Vympel R-73 air-to-air missiles, 2 KMGU-2 mine dispensers, and a variant of 9K333 Verba air-to-air missile[source] |
|---|
| Hover ceiling OGE | — | 3,600 m (11,811 ft)[source] |
|---|
| g limits | — | + 3 - 0.5[source] |
|---|
| Disk loading | — | 49.5 kg/m 2 (10.1 lb/sq ft) max[source] |
|---|
Maximum take-off; Max takeoff weight
270 km/h (170 mph, 150 kn) max[source]
