At a glance
Measured figures
Bell 412EP · including rotors
Single source56 ft 1 in (17.09 m) including rotors[source]
AS550 C3 · fuselage length
Single sourceConfiguration
| Specification | Bell 412 | Eurocopter Fennec |
|---|---|---|
| Type | Multipurpose utility helicopter[source] | Light utility military helicopter[source] |
| National origin | United States / Canada[source] | France[source] |
| Manufacturer | Bell Helicopter[source] | Aérospatiale Eurocopter Airbus Helicopters[source] |
| Primary users | Japan Ground Self Defence Force See Operators for others[source] |
AS550 C3 · overall length, rotors turning
Single source10.93 m (35 ft 10 in) (fuselage length), 12.94 m (42 ft 6 in) (overall length, rotors turning)[source]
Bell 412EP · 1 × Pratt & Whitney Canada PT6T-3D Twin-Pac or PT6T-3DF Twin-Pac coupled turboshaft engine - each, 1,250 shp (
Single source1 × Pratt & Whitney Canada PT6T-3D Twin-Pac or PT6T-3DF Twin-Pac coupled turboshaft engine - each, 1,250 shp (930 kW)[source]
AS550 C3 · 1 × Turbomeca Arriel 2B turboshaft 847 shp) (limited to
Single sourceAS550 C3 · 671 shp for take-off
Single source1 × Turbomeca Arriel 2B turboshaft , 632 kW (847 shp) (limited to 500 kW (671 shp for take-off))[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
French Army Light Aviation French Air and Space Force Argentine Naval Aviation Royal Danish Air Force Indonesian Army Aviation Center Royal Malaysian Navy Aviation Pakistan Army Aviation Corps[source] |
| Number built | 1,300+[source] | — |
|---|
| Manufactured | 1979–present[source] | 1990–present[source] |
|---|
| Introduction date | 1981 ( 1981 )[source] | 1990[source] |
|---|
| First flight | August 1979 ( 1979-08 )[source] | — |
|---|
| Developed from | Bell 212[source] | Eurocopter AS350 Écureuil Eurocopter AS355 Écureuil 2[source] |
|---|
| Variant | Bell CH-146 Griffon[source] | — |
|---|
| Capacity | up to 13 passengers, maximum external load of almost 6,614 lb (3,000 kg)[source] | 4 passengers[source] |
|---|
| Fuselage length | 43 ft (13 m)[source] | — |
|---|
| Blade sections | root: Boeing VR-7; tip: Wortmann FX 71-H-080[source] | — |
|---|
| Main rotor area | 1,662 sq ft (154.4 m 2 )[source] | 89.75 m 2 (966.1 sq ft) Royal Thai Army AS550 armed with .50" HMP POD[source] |
|---|
| Power/mass | 0.2663 hp/lb (0.4378 kW/kg)[source] | — |
|---|
| Status | — | In service[source] |
|---|
| Fuel capacity | — | 540 L (143 US Gal)[source] |
|---|
| Never exceed speed | — | 287 km/h (178 mph, 155 kn)[source] |
|---|
| Source measurement | — | Twelve AS550 C2helicopters were purchased by the Royal Danish Air Force in 1987, with the first helicopters delivered on August 1990. Due to a change in the geopolitical environment following the collapse of the Soviet Union and the end of the Cold War , the Fennec helicopters were gradually repurposed for other tasks, primarily observation and light transport duties. In 2003, they were primarily employed by the Eskadrille 724 . In 2002, 3 Danish Fennec helicopters were deployed to Macedonia during Operation Amber Fox . In December 2005, Fennec helicopters were deployed to support the Danish forces in Iraq and from August 2007, 4 more were deployed to the troubled country as a replacement for the withdrawn ground troops. In 2008, 4 Fennec helicopters were deployed to the Danish forces in Afghanistan . As a result of various defense agreements, the number of active Fennecs in the Air Force has been reduced to 8 in 2006.[source]Eurocopter Fennec · Operational history; only the objects and conditions stated in this passage AS555 AN Fennec 2 – Armed military version, can be fitted with a 20 mm cannon.[source]Eurocopter Fennec · Variants; only the objects and conditions stated in this passage Capacity: 4 passengers[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Length: 10.93 m (35 ft 10 in) (fuselage length), 12.94 m (42 ft 6 in) (overall length, rotors turning)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Height: 3.34 m (10 ft 11 in)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Empty weight: 1,220 kg (2,690 lb)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Max takeoff weight: 2,250 kg (4,960 lb)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Powerplant: 1 × Turbomeca Arriel 2B turboshaft , 632 kW (847 shp) (limited to 500 kW (671 shp for take-off))[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Main rotor diameter: 10.69 m (35 ft 1 in)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Main rotor area: 89.75 m 2 (966.1 sq ft) Royal Thai Army AS550 armed with .50" HMP POD[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Maximum speed: 246 km/h (153 mph, 133 kn) (max cruise)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Never exceed speed : 287 km/h (178 mph, 155 kn)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Range: 648 km (403 mi, 350 nmi)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Service ceiling: 5,280 m (17,320 ft)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Rate of climb: 10.30 m/s (2,028 ft/min)[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage 20 mm Giat M621 cannon[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage Fabrique Nationale de Herstal twin 7.62 mm or 12.7 mm machine gun pods[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage 7 x 70mm (2.75") Forges de Zeebrugge rocket launcher FZ220 or 12 x 68 mm Thales Brandt rockets[source]Eurocopter Fennec · Specifications (AS550 C3); only the objects and conditions stated in this passage |
|---|
