At a glance
Measured figures
206B Jetranger II · including rotors
Single source38 ft 9.5 in (11.824 m) including rotors[source]
Bell 407 · Length
Configuration
| Specification | Bell 206 | Bell 407 |
|---|---|---|
| Type | Multipurpose utility helicopter[source] | Multipurpose utility helicopter[source] |
| National origin | United States / Canada[source] | United States/Canada[source] |
| Manufacturer | Bell Helicopter[source] | Bell Helicopter[source] |
| Status | In service[source] | In service[source] |
41 ft 8 in (12.70 m)[source]
Cruise; 206B Jetranger II · at MTOW, 5,000 feet
Single sourceMaximum; 206B Jetranger II · at MTOW (sea level)
Single source122 kn (140 mph, 226 km/h) at MTOW (sea level)[source]
120 kn (140 mph, 220 km/h) at MTOW, 5,000 feet[source]
Cruise; Bell 407 · Cruise speed
Single sourceMaximum; Bell 407 · Maximum speed
Single source206B Jetranger II · 1,350 ft/min (
Single source1,350 ft/min (6.9 m/s)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Number built | 7,300[source] | 1600+ (Feb 2023)[source] |
|---|
| Manufactured | 1962–2017[source] | 1995–present[source] |
|---|
| Introduction date | 1967[source] | 1996[source] |
|---|
| First flight | December 8, 1962 (206) January 10, 1966 (206A)[source] | 29 June 1995[source] |
|---|
| Developed from | Bell YOH-4[source] | Bell 206L LongRanger[source] |
|---|
| Variants | Bell OH-58 Kiowa Bell 407[source] | — |
|---|
| Developed into | Bell 400 TwinRanger[source] | Bell 427 Northrop Grumman MQ-8C Fire Scout[source] |
|---|
| Capacity | 4 passengers[source] | Typical seating configuration for seven comprising pilot and passengers, with five passengers in main cabin / 2,347 lb (1,065 kg) internal payload / Max hook capacity 1,200 kg (2,646 lb).[source] |
|---|
| Fuselage length | 31 ft 2 in (9.50 m)[source] | — |
|---|
| Interior dimensions | 7 ft 2 in (2.18 m) length, by 4 ft 2 in (1.27 m) width, by 4 ft 3 in (1.30 m) height, plus 16 ft 3 (453 L) baggage compartment[source] | — |
|---|
| Main rotor area | 873 sq ft (81.1 m 2 )[source] | 962 sq ft (89.4 m 2 )[source] |
|---|
| Blade section | – NACA 0012 mod (11.3%)[source] | - root: Boeing VR-7; tip: Narramore 8%[source] |
|---|
| Maximum speed at 5,000 ft | 116 kn (133 mph; 215 km/h) at MTOW[source] | — |
|---|
| Disk loading | 4 lb/sq ft (20 kg/m 2 )[source] | — |
|---|
| Power/mass | 0.09 hp/lb (0.15 kW/kg)[source] | — |
|---|
| Variant | — | Bell ARH-70 Arapaho[source] |
|---|
