At a glance
Measured figures
UC-45 Expeditor · Length
Single source34 ft 3 in (10.44 m)[source]
FTC-2000 · excluding nose-probe
Configuration
| Specification | Beechcraft Model 18 | Guizhou JL-9 |
|---|---|---|
| Type | Trainer , transport aircraft and utility aircraft[source] | Advanced jet trainer Light combat aircraft[source] |
| National origin | United States[source] | — |
| Manufacturer | Beech Aircraft Corporation[source] | Guizhou Aviation Industry Import/Export Company (GAIEC)[source] |
| Status | In service[source] | In service[source] |
14.555 m (47 ft 9 in) excluding nose-probe[source]
UC-45 Expeditor · at 160 mph (260 km/h; 140 kn) and
Single sourceUC-45 Expeditor · Range
Single source1,200 mi (1,900 km, 1,000 nmi) at 160 mph (260 km/h; 140 kn) and 5,000 ft (1,500 m)[source]
Ferry; FTC-2000 · with maximum internal and external fuel
Single sourceFTC-2000 · on internal fuel
Single sourceUC-45 Expeditor · 2 × Pratt & Whitney R-985-AN-1 "Wasp Junior" radial engines each
Single source2 × Pratt & Whitney R-985-AN-1 "Wasp Junior" radial engines , 450 hp (340 kW) each[source]
FTC-2000 · 1 × Guizhou Liyang WP-13F (C) afterburning turbojet thrust dry
Single sourceFTC-2000 · thrust dry and
Single sourceFTC-2000 · with afterburner
Single sourceFTC-2000 · with afterburner (1 × WP-14C Kunlun-3 for FTC-2000G
Single source1 × Guizhou Liyang WP-13F (C) afterburning turbojet, 43.15 kN (9,700 lbf) thrust dry, 63.25 kN (14,220 lbf) with afterburner (1 × WP-14C Kunlun-3 for FTC-2000G, 53.89 kN (12,110 lbf) thrust dry and 76.53 kN (17,200 lbf) with afterburner.)[source]
FTC-2000 · Endurance
Single source3 hours[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Primary users | United States Army Air Forces United States Navy Royal Air Force Royal Canadian Air Force[source] | People's Liberation Army Air Force People's Liberation Army Navy Air Force Myanmar Air Force Sudanese Air Force[source] |
|---|
| Number built | 9,000+[source] | — |
|---|
| Manufactured | 1937–1970[source] | — |
|---|
| Introduction date | 1937[source] | — |
|---|
| First flight | 15 January 1937[source] | 13 December 2003[source] |
|---|
| Capacity | 6 passengers[source] | — |
|---|
| Designer | — | Aero Engine Research Institute of Guizhou Aviation Industry Corporation[source] |
|---|
| Developed from | — | Chengdu JJ-7[source] |
|---|
| Fuel capacity | — | 2,000 kg (4,409 lb) internal + up to 1,302 kg (2,870 lb) in external tanks[source] |
|---|
| Guns | — | 1 × 23 mm cannon[source] |
|---|
| Hardpoints | — | 5 with a capacity of 2,000 kg (4,409 lb) maximum, with provisions to carry combinations of: Other: up to 3 x fuel tanks[source] |
|---|
| Unstick and touchdown speed | — | 260 km/h (160 mph; 140 kn)[source] |
|---|
| Minimum flying speed | — | 210 km/h (130 mph; 110 kn)[source] |
|---|
| Stall speed | — | 125 km/h (78 mph, 67 kn)[source] |
|---|
| g limits | — | + 8 - 3[source] |
|---|
| Wing loading | — | 374.8 kg/m 2 (76.8 lb/sq ft)[source] |
|---|
| Thrust/weight | — | 0.00645 kN/kg (0.658 lb f /lb)[source] |
|---|
| Take-off run | — | 400–500 m (1,300–1,600 ft)[source] |
|---|
| Landing run | — | 700 m (2,300 ft)[source] |
|---|
| Other | — | up to 3 x fuel tanks[source] |
|---|
| Missiles | — | ** Short range air-to-air missile 2 × PL-8 AAMs (on inboard pylons) 2 × PL-9 AAMs (on outboard pylons) Beyond-visual-range air-to-air missiles SD-10 (Only on FTC-2000G) Anti-radiation missiles CM-102 (Only on FTC-2000G)[source] |
|---|
| Beyond-visual-range air-to-air missiles | — | SD-10 (Only on FTC-2000G)[source] |
|---|
| Anti-radiation missiles | — | CM-102 (Only on FTC-2000G)[source] |
|---|
| Country of origin | — | Volksrepublik China[source]Country of design · Entwurfsland |
|---|
| Reported operators | — |
|
|---|
