At a glance
Al-Khalid tanklarger figure on 0 of 1
K2 Black Panther
Measured figures
Length
Single source10.07 m (33 ft 0 in)[source]
Chassis
Single sourceConfiguration
| Specification | Al-Khalid tank | K2 Black Panther |
|---|---|---|
| Type | Main battle tank[source] | Main battle tank[source] |
| Place of origin | Pakistan / China[source] | South Korea[source] |
| In service | 2001 – present[source] | 2014–present[source] |
| Used by | Operators[source] | See Operators[source] |
Counts only measures both sources give with the same scope. A larger figure is not a better system.
Overall
Single sourceOverall: 10.8 meters (35 ft 5 in) Chassis : 7.5 meters (24 ft 7 in)[source]
Maximum; Maximum speed
Single source72 km/h (45 mph)[source]
Maximum; Cross country Acceleration from
Single sourceMaximum; Paved road
Single sourcePaved road: 70 km/h (43 mph) Cross country: 50 km/h (31 mph) Acceleration from 0–32 km/h (0–20 mph) in 7.47 seconds (MT883 Ka-501) or 8.77 seconds (DV27K)[source]
KMDB 6TD-2 6-cylinder diesel
Single sourceKMDB 6TD-2 6-cylinder diesel 1,200 hp (890 kW)[source]
Batch I: STX Engine/ MTU Friedrichshafen MT883 Ka-501 4- short stroke , 12-cylinder water-cooled diesel, dry weight: 2,064 kg Batch II-IV: HD Hyundai Infracore DV27K 4- long stroke , 12-cylinder water-cooled diesel, dry weight: 2,550 kg
Single sourceEngine
Single sourceBatch I: STX Engine/ MTU Friedrichshafen MT883 Ka-501 4- short stroke , 12-cylinder water-cooled diesel, dry weight: 2,064 kg 1,500 hp (1,103 kW) Batch II-IV: HD Hyundai Infracore DV27K 4- long stroke , 12-cylinder water-cooled diesel, dry weight: 2,550 kg 1,500 hp (1,110 kW)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Designer | Norinco[source] | Agency for Defense Development Hyundai Rotem Poongsan Corporation Hanwha Systems Samyang Comtech Hyundai WIA Doosan Mottrol[source] |
|---|
| Designed | 1993–1999[source] | 1995–2008[source] |
|---|
| Manufacturer | Norinco (VT-1A/MBT-2000, Type 96-IIM) Heavy Industries Taxila (Al Khalid, Al Khalid-1)[source] | Hyundai Rotem[source] |
|---|
| Unit cost | US$4.7 million – US$5.8 million in 2011[source] | ₩ 7.8 billion (production batch 1) US$ 8.5 million (constant 2009 USD)[source] |
|---|
| Produced | 2001 – 2014 (Al-Khalid) 2020 – present (Al-Khalid-1)[source] | 2008–present[source] |
|---|
| Variants | Pakistani: Al-Khalid Al-Khalid I Chinese: Type 90-IIM / MBT-2000 VT-1A[source] | — |
|---|
| Armour | Composite armour , RHA , ERA[source] | — |
|---|
| Main armament | Al-Khalid: 125 mm smoothbore gun, 39 rounds Al-Khalid I: 125 mm smoothbore gun, 49 rounds[source] | Hyundai WIA CN08 120 mm 55 caliber smoothbore gun (40 rounds, 16 available in the bustle autoloader )[source] |
|---|
| Secondary armament | Al-Khalid: 7.62 mm coaxial machine gun , 3000 rds 12.7 mm external AA machine gun, 500 rds Al-Khalid I: 7.62 mm coaxial machine gun , 7,100 rds 12.7 mm external AA machine gun, 1,500 rds[source] | 1× 12.7×99mm NATO K6 heavy machine gun (3,200 rounds) 1× 7.62×51mm NATO coaxial machine gun (12,000 rounds)[source] |
|---|
| Power/weight | 26 hp/ton[source] | 27.3 hp/t (20.35 kW/t)[source] |
|---|
| Transmission | 7 forward and 4 reverse gears, Semi-automatic[source] | Batch I-III: RENK HSWL 295 TM (5 forward, 5 reverse gears), dry weight: 2,450 kg Batch IV: SNT Dynamics EST15K (6 forward, 3 reverse gears), dry weight: 2,500 kg[source] |
|---|
| Suspension | Torsion bar with hydraulic dampers[source] | Semi-active in-arm suspension unit (ISU) with dynamic track tension system (DTTS)[source] |
|---|
| No. built | — | Republic of Korea Army : Batch I: 100, Batch II: 106, Batch III: 54, Batch IV: 150 (ordered) Polish Land Forces : Batch I: 180, Batch II: 180 (ordered) Total: 440[source] |
|---|
| Armor | — | MIL-12560H armor steel and silicon carbide non-oxide ceramic plate along with ERA add-on armor[source] |
|---|
| Fuel capacity | — | 1,296 liters (342 U.S. gal)[source] |
|---|
| Reported operators |
| — |
|---|
