At a glance
2B11larger figure on 2 of 2
M69 mortarlarger figure on 0 of 2
Counts only measures both sources give with the same scope. A larger figure is not a better system.
Measured figures
Length
Single source1,324 millimetres (52.1 in)[source]
Configuration
| Specification | 2B11 | M69 mortar |
|---|---|---|
| Type | Mortar[source] | Mortar[source] |
| Place of origin | Soviet Union[source] | Yugoslavia[source] |
| In service | 1981–present[source] | — |
| Wars | Soviet–Afghan War Russo-Ukrainian War[source] | — |
| Designed | 1981[source] | — |
Effective; Maximum
Single sourceEffective; Minimum
Single sourceMaximum; 2B11; infobox maximum firing range
Single sourceMinimum: 0.46 km (0.29 mi) Maximum: 7.18 km (4.46 mi)[source]
Maximum: 7.18 km (4.46 mi)[source]2B11; infobox maximum firing range
Максимальная дальность, м 9000 ( КМ-8 «Грань» )[source]
Maximum; Maximum firing range
Single source4,943 metres (16,217 ft)[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
| Manufacturer | Motovilikhinskiye Zavody Special Engineering and Metallurgy JSC[source] | — |
|---|
| Shell | HE , smoke , illuminating and incendiary[source] | — |
|---|
| Shell weight | 16.8 kg (37 lb)[source] | — |
|---|
| Carriage | 2F510 2x1 wheeled transport chassis, GAZ-66 4×4 truck ( prime mover )[source] | — |
|---|
| Elevation | 45–80°[source] | 45°–85°[source] |
|---|
| Traverse | ±5° (without bipod repositioning)[source] | 5.6°[source] |
|---|
| Sights | MPM-44M[source] | NSB-3[source] |
|---|
| Designer | — | Military Technical Institute[source] |
|---|
| Feed system | — | muzzle-loaded[source] |
|---|
| Reported operators |
|
|
|---|
