AArtillery
At a glance
2A36 Giatsint-Blarger figure on 1 of 3
SU-100larger figure on 2 of 3
Counts only measures both sources give with the same scope. A larger figure is not a better system.
Measured figures
Maximum; Maximum speed
Single source48 km/h (30 mph)[source]
Maximum; Maximum firing range
Single source27,000–40,000 m (30,000–44,000 yd)[source]
Operational; Cross-country
Single sourceOperational; Cross-country with additional fuel tanks
Single sourceOperational; Road
Single sourceOperational; with additional fuel tanks
Single sourceRoad: 250 km (160 mi) 320 km (200 mi) (with additional fuel tanks) Cross-country: 140 km (87 mi) 180 km (110 mi) (with additional fuel tanks)[source]
V-2-34 based on the Kharkiv Model V-2
Single sourceV-2-34 based on the Kharkiv Model V-2 500 hp (370 kW)[source]
Barrel length
Single source8.197 m (26.89 ft)[source]
Rate of fire
Single source6 rounds per minute[source]
Bars compare reported quantities only. A larger figure does not make a system better; configurations and test conditions differ.
Configuration
| Specification | 2A36 Giatsint-B | SU-100 |
|---|---|---|
| Place of origin | Soviet Union[source] | Soviet Union[source] |
| In service | 1976−present[source] | October 1944 – present[source] |
| Used by | See operators[source] | — |
| Wars | Gulf War Second Nagorno-Karabakh War Russo-Ukrainian War[source] | World War II Suez Crisis Vietnam War Bay of Pigs Invasion Six-Day War Yom Kippur War Iran–Iraq War Yemeni Civil War (2014-present)[source] |
| Designer | Yuri Kalachnikov[source] | — |
| Designed | 1968−1975[source] | 1944[source] |
| Manufacturer | Motovilikha Plants[source] | Uralmash[source]SU-100 original Soviet manufacture at UZTM, explicitly also called Uralmash; not an exclusive manufacturer or licensed-production claim |
| Unit cost | US$ 500,000−600,000 (export price, 1995)[source] | $448,000 (vehicle's unit price for Morocco in 1967)[source] |
| Produced | 1976−1980s[source] | — |
| No. built | 1,500[source] | 4,976[source] |
| Shell | 152.4 mm (6.00 in)[source] | — |
| Calibre | 49[source] | — |
| Breech | Horizontal sliding-block[source] | — |
| Carriage | Split trail[source] | — |
| Elevation | 57°[source] | — |
| Traverse | 25°[source] | — |
| Type | — | Self-propelled anti-tank gun[source] |
| Armor | — | front: 75 mm (3 in) sides: 45 mm (1.77 in) rear: 45 mm (1.77 in) roof: 20 mm (.78 in)[source] |
| Main armament | — | 100 mm D-10S gun[source] |
| Power/weight | — | 15.8 hp/tonne[source] |
| Suspension | — | Christie[source] |
| Reported operators |
|
|
